Preferred method of drilling pen blanks

I was just curious how every one is drilling their pen blanks, wether it be on the lathe or a drill press and what jig you use as I am trying to find a new method. Currently I use a machinist vise which works, but it could be quicker and more accurate. Any pictures, especially of home made jigs, would be awesome!!
David.
davidpensfan87 is offline
Sponsored Links
Advertisement

post #2 of 10 Old 05-02-2012, 10:36 PM
Senior Member

sawdustfactory's Avatar

Join Date: Jan 2011
Location: North Bend, WA
Posts: 4,801
View sawdustfactory's Photo Album My Photos
I use a wood screw to hold the blank and drill press.

That bowl was perfect right up until that last cut...
sawdustfactory is offline
post #3 of 10 Old 05-03-2012, 01:59 AM
The New Guy

Join Date: Dec 2011
Location: Down south, where the food is good.
Posts: 1,200
View Itchytoe's Photo Album My Photos
I use a 4 jaw chuck and drill chuck on the lathe. Perfectly centered every time, unless I somehow screw up chucking the blank.
Itchytoe is offline
Sponsored Links
Advertisement

post #4 of 10 Old 05-03-2012, 04:02 AM
No Longer Here

Join Date: Feb 2009
Posts: 6,847
View rrbrown's Photo Album My Photos
I use one like this

rrbrown is offline
post #5 of 10 Old 05-03-2012, 11:04 AM
Senior Member

Whaler's Avatar

Join Date: Mar 2011
Location: Sequim, WA
Posts: 264
View Whaler's Photo Album My Photos
I drill on the lathe using my 4 jaw chuck.
Whaler is offline
post #6 of 10 Old 05-03-2012, 12:01 PM
Senior Member

Join Date: Feb 2010
Location: Whittier, CA. USA
Posts: 344
View jlord's Photo Album My Photos
I drilling on the drill press using this vise from Woodcraft.


For when I drill on the lathe I use this chuck.


http://www.woodcraft.com/product/208...ling-vise.aspx

http://www.pennstateind.com/mm5/merc...huck&x=12&y=25

James
Whittier, CA.

Just because you can, doesn't always mean you should!
jlord is offline
post #7 of 10 Old 05-03-2012, 08:05 PM
Member

Join Date: Apr 2012
Posts: 33
View clapiana's Photo Album My Photos
I have a Paul Huffman Vise on my drill press. Classicnib is a reseller of these high quality vises
clapiana is offline
post #8 of 10 Old 05-09-2012, 08:42 PM
Junior Member

Join Date: Dec 2009
Posts: 4
View Hoosierbob11's Photo Album My Photos
I have found the key to be the bit. Colt makes a great one. Gotta be sharp and keep it cool.
Hoosierbob11 is offline
post #9 of 10 Old 05-09-2012, 11:10 PM
No Longer Here, BY CHOICE

Join Date: Nov 2010
Posts: 2,442
View BassBlaster's Photo Album My Photos
I drill on the drill press with a home made jig.



I dunno thats its a prefered method but it works just fine and I didnt pay 50 bucks or more for it. In fact it cost me less than a buck to make. I also only use Wood River pen makers bits for pen blank drilling.

I do have some pin jaws for my chuck that would hold a pen blank real well and have been thinking about that but I dont like the idea of changing the jaws everytime I want to drill a pen blank.

RRBrown, knottscott and many others were banned, they didn't just leave. They were banned for standing up to the new owners that are destroying this site. Come join us all at woodworking chat, the best new woodworking site on the net!!
BassBlaster is offline
post #10 of 10 Old 05-10-2012, 01:08 AM Thread Starter
Senior Member

davidpensfan87's Avatar

Join Date: Apr 2012
Location: Kansas City Missouri
Posts: 134
View davidpensfan87's Photo Album My Photos
Quote:
Originally Posted by BassBlaster
I drill on the drill press with a home made jig.

I dunno thats its a prefered method but it works just fine and I didnt pay 50 bucks or more for it. In fact it cost me less than a buck to make. I also only use Wood River pen makers bits for pen blank drilling.

I do have some pin jaws for my chuck that would hold a pen blank real well and have been thinking about that but I dont like the idea of changing the jaws everytime I want to drill a pen blank.
Cool thanks, I agree with you about spending big bucks for a vise. My uncle left his wood river vise in the shop, I have been taking full advantage of it, that one costs 90 bucks!!! Too much for me!
davidpensfan87 is offline
