Sanding Belt Breakage

I have an older Sears Craftsman, hand held, belt sander, 3 X 21. Probably 20 - 30 years old but it still runs OK. I tried to use it today to sand a wood base I made for my arbor press (2" x 10" x 24" +/-). It should have been a snap of a job. But inside of 10 minutes I/it broke four sanding belts, two used and two new. All four of these belts were purchased at least four years ago, probably five or maybe even six. All but the one on the sander were stored in an air conditioned room. They were two different brands, B&D and Ace, I think. I had to use my newer, smaller B&D sander to complete the job and it worked without breaking any belts.

This brought back some memories. I have observed that if I used belts that were a year or more old on that Sears sander, they would break quickly. I do wood work infrequently and think I always had to buy new belts for every job where I used this sander.

My question is are there better and lesser brands of sanding belts? Or is this sander just a belt eater? If it is the sander I can easily buy a new one in that size for less than my cost in belts over the years. If it is the belts, what brands will last longer? Hang the cost, a $1 belt that breaks in under 5 minutes is a total waste and a $50 one that lasts is a great bargain.
EPAIII is offline
Sponsored Links
Advertisement

post #2 of 18 Old 04-07-2016, 09:04 PM
Senior Member

mat 60's Avatar

Join Date: Jul 2012
Location: Readfield ME
Posts: 449
View mat 60's Photo Album My Photos
I no what your saying about old belts but do you realy want to spend big money on a belt that sits for years in the shop.
mat 60 is offline
The Following User Says Thank You to mat 60 For This Useful Post:
WesTex (04-07-2016)
post #3 of 18 Old 04-07-2016, 09:12 PM
Senior Member

Join Date: Jul 2008
Location: Florida Panhandle
Posts: 11,596
View GeorgeC's Photo Album My Photos
Age is the enemy of old sanding belts. Regardless of brand. I have the same sander that you have (assume it is the old heavy aluminum bodied sander) and a quantity of old belts. Sometimes one will still be good, but more often than not the old belt will come apart at the glued seam.

George
GeorgeC is offline
Sponsored Links
Advertisement

post #4 of 18 Old 04-07-2016, 09:21 PM
Senior Member

Join Date: Aug 2012
Location: British Columbia, Canada
Posts: 4,895
View FrankC's Photo Album My Photos
Interesting, I seldom use mine and haven't bought a new belt for years, I just pull it out and use it when I need it with what ever suitable grit of old belt I have around, never had a belt come apart.

Are you putting the belts on so they run in the right direction?

“Everything we hear is an opinion, not a fact. Everything we see is a perspective, not the truth.”
― Marcus Aurelius
FrankC
http://sawdustmaking.com
FrankC is offline
post #5 of 18 Old 04-07-2016, 09:27 PM
Senior Member

Join Date: Dec 2011
Location: Maurice, LA
Posts: 489
View tvman44's Photo Album My Photos
Get some brand new belts.

Bob making sawdust in SW Louisiana
with a EX-21
tvman44 is offline
post #6 of 18 Old 04-07-2016, 09:33 PM
Senior Member

Join Date: Nov 2012
Location: Syracuse, NY
Posts: 312
View Tom-G's Photo Album My Photos
My Craftsman is at least 30 years old. I also don't ever recall breaking a belt.
Tom-G is offline
post #7 of 18 Old 04-07-2016, 09:35 PM
Senior Member

gmcooter's Avatar

Join Date: Jan 2015
Posts: 211
View gmcooter's Photo Album My Photos
I have a crafts 4x24 sander that I have had for several years. I used to get most of my belts at ace but they weer easily broken even new. I now buy the ceramic belts at Lowes. They are a little more expensive than the other types but they last a lot longer. I usually wear them completely out before they break. I have used one for 6 months to a year before they break. I think they are worth the extra expense. Toyman
gmcooter is offline
post #8 of 18 Old 04-07-2016, 09:35 PM
Moderator

Steve Neul's Avatar

Join Date: Sep 2011
Posts: 25,758
View Steve Neul's Photo Album My Photos
It may be the Sears sander tensions the belts a little tighter but without being there and seeing the sander I would say the fault is with the belts. Forgive me but a lot of sanding belts are directional. Could it be you are putting them on backwards? Some belts have an arrow on the inside showing the direction they should run. On those type belts you can easily break them running backwards.
Steve Neul is online now
post #9 of 18 Old 04-07-2016, 09:56 PM
where's my table saw?

woodnthings's Avatar

Join Date: Jan 2009
Location: SE, Michigan
Posts: 25,293
View woodnthings's Photo Album My Photos
old belts break

http://www.woodworkingtalk.com/f12/sanding-belts-4212/

Several past threads here deal with older belts breaking often. Something about the storage environment or humidty, I donno? Maybe they were made by a manufacturer that had faulty equipment, I doono? They are not "glued" together if I recall. I think they are bonded with heat and pressure, probably like a hot glue, which if subjected to heat buildup or extra tension or both the bond will fail. JMO.

http://www.woodcentral.com/woodworki...elts-question/

The answer to your question will only be as detailed and specific as the question is detailed and specific. Good questions also include a sketch or a photo that illustrates your issue. (:< D)

Last edited by woodnthings; 04-07-2016 at 10:25 PM.
woodnthings is online now
post #10 of 18 Old 04-07-2016, 10:08 PM
Junior Member

Join Date: Dec 2014
Posts: 25
View CrazyHorse's Photo Album My Photos
The adhesive that holds the belts together ages and fails, it is a simple fact. Even under ideal conditions, they will fail. I'm betting new belts will do fine.
CrazyHorse is offline
post #11 of 18 Old 04-07-2016, 11:07 PM
Senior Member

OnealWoodworking's Avatar

Join Date: Apr 2013
Posts: 1,128
View OnealWoodworking's Photo Album My Photos
Quote:
Originally Posted by EPAIII View Post

My question is are there better and lesser brands of sanding belts? Or is this sander just a belt eater? If it is the sander I can easily buy a new one in that size for less than my cost in belts over the years. If it is the belts, what brands will last longer? Hang the cost, a $1 belt that breaks in under 5 minutes is a total waste and a $50 one that lasts is a great bargain.
The 3M brand are the best in my opinion with respect to this discussion about breakage.

They will not care what 'direction' you run them in either for the most part as far as 'exploding' is concerned. Your cut will be different and you will likely have to make tracking adjustments but the belt is not simply going to explode if you forget to mark it and ran it in the wrong direction.


If direction is important to you when using your belt sander you may wish to keep a sharpie in your pocket so you can mark the insides of the belts when changing them. Even with the 3M belts - The factory markings on the inside of the belt will be gone long before the working surface is toasted. A simple 'x' on the outside edge before removal is going to last a good while before it too is gone...


There are plenty of brands of cheaper belts that will explode in a very short time even IF used on a good belt sander with a fairly clean and flat shoe.

Unless your shoe (part on bottom that is flat and belt rides over) is badly damaged and gouged up you should not be 'eating' belts. The shoe is a part that you should consider as disposable and replace or repair as needed.



You want that part to be flat and smooth if you can help it.
OnealWoodworking is offline
post #12 of 18 Old 04-08-2016, 12:27 AM Thread Starter
Senior Member

Join Date: Mar 2012
Location: Beaumont, Texas
Posts: 114
View EPAIII's Photo Album My Photos
Yes, yes, yes, I am running them in the correct direction.

This is not an aluminum model. It is black plastic and came in a black plastic carrying case.



Quote:
Originally Posted by FrankC View Post
Interesting, I seldom use mine and haven't bought a new belt for years, I just pull it out and use it when I need it with what ever suitable grit of old belt I have around, never had a belt come apart.

Are you putting the belts on so they run in the right direction?
EPAIII is offline
post #13 of 18 Old 04-08-2016, 12:31 AM Thread Starter
Senior Member

Join Date: Mar 2012
Location: Beaumont, Texas
Posts: 114
View EPAIII's Photo Album My Photos
I am going to look for them. Or the 3M brand.

The tension on this model is quite high. I have to "cock" it by putting about half my weight on the front roller to get the belts on or off. Is there any recommended tension for a belt this size?



Quote:
Originally Posted by toyman View Post
I have a crafts 4x24 sander that I have had for several years. I used to get most of my belts at ace but they weer easily broken even new. I now buy the ceramic belts at Lowes. They are a little more expensive than the other types but they last a lot longer. I usually wear them completely out before they break. I have used one for 6 months to a year before they break. I think they are worth the extra expense. Toyman
EPAIII is offline
post #14 of 18 Old 04-08-2016, 07:07 AM
Senior Member

Join Date: Jul 2014
Location: WNC
Posts: 224
View UnisawGuy's Photo Album My Photos
I have used only Klingspor sanding products for 24 years, and have never had a joint fail on a belt. The abrasive wears out first. There have been several operator induced malfunctions, especially when I was learning how to use a belt sander.
I purchased a thickness sander in 2007, the 4x24 belts I am using now were purchased prior to 2007.
UnisawGuy is offline
post #15 of 18 Old 04-08-2016, 07:41 AM
Moderator

Steve Neul's Avatar

Join Date: Sep 2011
Posts: 25,758
View Steve Neul's Photo Album My Photos
I think as rare event as belt breakage is I think if you would change to any brand other than what you are using it would solve the problem.

If you are having to put that much pressure on the tensioner I think it needs maintenance. I think it's more friction than the spring. They get gummed up with dust after a while and need a thorough cleaning. Blow it out real good with compressed air and lube with some dry lubricant. If you bought the sander used you might take it apart and clean it. Someone might have used motor oil on it making it worse.
Steve Neul is online now
post #16 of 18 Old 04-08-2016, 11:56 AM
Senior Member

Join Date: Aug 2012
Location: British Columbia, Canada
Posts: 4,895
View FrankC's Photo Album My Photos
Here is a good use for those broken belts:
http://benchnotes.com/Sanding%20Bloc...ing_Block.html

“Everything we hear is an opinion, not a fact. Everything we see is a perspective, not the truth.”
― Marcus Aurelius
FrankC
http://sawdustmaking.com
FrankC is offline
post #17 of 18 Old 04-08-2016, 06:58 PM
Really underground garage

Join Date: Aug 2010
Location: mnts of Va
Posts: 2,553
View BWSmith's Photo Album My Photos
EPA,Paul?

We're a Klingspor shop as well(posted above,Unisawguy).If it survives here,no normal shop is going to have issues.We grind(sand)exotic woods and all manor of plastics in bow(archery)production.
BWSmith is offline
post #18 of 18 Old 04-08-2016, 08:11 PM
Senior Member

OnealWoodworking's Avatar

Join Date: Apr 2013
Posts: 1,128
View OnealWoodworking's Photo Album My Photos
Quote:
Originally Posted by EPAIII View Post
I am going to look for them. Or the 3M brand.

The tension on this model is quite high. I have to "cock" it by putting about half my weight on the front roller to get the belts on or off. Is there any recommended tension for a belt this size?
You want it to be enough to keep the belt from slipping while under normal use / load.

Please try and do what Steve suggested and blow everything out really good. Make sure all your parts are clean and in proper working order.

OnealWoodworking is offline
