Routing/Dadoing Melamine and tear/chip out.

I'm building some built ins for our guest walk in closet. I've got a ton of 5/8s and 3/4s melamine that will work perfectly but I've always used a router to rabbit out slots for the shelves. I'm worried about the melamine chipping all over the place when I use the dado blade or my trusty router. Any insight or advice? I've never used melamine before.


Ut Prosim
Taylormade is offline
Sponsored Links
Advertisement

post #2 of 10 Old 02-09-2011, 08:57 AM
Old School

cabinetman's Avatar

Join Date: Jul 2007
Location: So. Florida
Posts: 24,027
View cabinetman's Photo Album My Photos
Quote:
Originally Posted by Taylormade View Post
I'm building some built ins for our guest walk in closet. I've got a ton of 5/8s and 3/4s melamine that will work perfectly but I've always used a router to rabbit out slots for the shelves. I'm worried about the melamine chipping all over the place when I use the dado blade or my trusty router. Any insight or advice? I've never used melamine before.

I think you'll have better luck with routing, using a good carbide tipped bit. Some joinery with melamine only has to break the surface to get a glue joint. IOW, instead of a butt joint, dado 1/8" deep and use any Titebond glue. You may find info on Roo Glue for melamine. I do not recommend it.

You may consider only fixing one or two shelves (depending on the height of the cabinet) to keep the cabinet shape. The rest of the shelves, just drill shelf clip holes and make them adjustable. That way if any get damaged or deflected they can be replaced/flipped over.








.
cabinetman is offline
The Following User Says Thank You to cabinetman For This Useful Post:
Taylormade (02-09-2011)
post #3 of 10 Old 02-09-2011, 09:12 AM
In History is the Future

firemedic's Avatar

Join Date: Dec 2010
Location: South Louisiana - Gonzales
Posts: 6,423
View firemedic's Photo Album My Photos
Quote:
Originally Posted by Taylormade
I'm building some built ins for our guest walk in closet. I've got a ton of 5/8s and 3/4s melamine that will work perfectly but I've always used a router to rabbit out slots for the shelves. I'm worried about the melamine chipping all over the place when I use the dado blade or my trusty router. Any insight or advice? I've never used melamine before.

I rabbited some melamine recently for t-tracks on a router table that's still in progress... Had no trouble at all... And I made it one pass! Lol...
Attached Images

firemedic is offline
The Following User Says Thank You to firemedic For This Useful Post:
Taylormade (02-09-2011)
Sponsored Links
Advertisement

post #4 of 10 Old 02-09-2011, 12:33 PM
Member

Join Date: Feb 2011
Posts: 34
View U8dust's Photo Album My Photos
Masking tape over the dado joint. A good sharp bit and a steady hand. Cut through the tape and it will help with chipping.
U8dust is offline
The Following User Says Thank You to U8dust For This Useful Post:
Taylormade (02-09-2011)
post #5 of 10 Old 02-09-2011, 01:14 PM
OLD DUDE AT WORK

H. A. S.'s Avatar

Join Date: Sep 2010
Location: IN
Posts: 1,460
View H. A. S.'s Photo Album My Photos
Quote:
Originally Posted by firemedic View Post
I rabbited some melamine recently for t-tracks on a router table that's still in progress... Had no trouble at all... And I made it one pass! Lol...


Looks like that will be one sweet router table.

Harrison, at your service!
H. A. S. is offline
post #6 of 10 Old 02-09-2011, 04:30 PM Thread Starter
Senior Member

Taylormade's Avatar

Join Date: Feb 2011
Location: Tampa, FL
Posts: 1,733
View Taylormade's Photo Album My Photos
Quote:
Originally Posted by H. A. S. View Post
Looks like that will be one sweet router table.

Man, it sure as heck does... do you have a thread for the progress of that bad boy?

Ut Prosim
Taylormade is offline
post #7 of 10 Old 02-09-2011, 04:34 PM Thread Starter
Senior Member

Taylormade's Avatar

Join Date: Feb 2011
Location: Tampa, FL
Posts: 1,733
View Taylormade's Photo Album My Photos
BTW, Cabinetman, I saw your router dado jig and I plan on using it tonight. Thanks for that. Looks brilliantly simple. I need that, ha.

Ut Prosim
Taylormade is offline
The Following User Says Thank You to Taylormade For This Useful Post:
cabinetman (02-09-2011)
post #8 of 10 Old 02-09-2011, 07:02 PM
In History is the Future

firemedic's Avatar

Join Date: Dec 2010
Location: South Louisiana - Gonzales
Posts: 6,423
View firemedic's Photo Album My Photos
Quote:
Originally Posted by H. A. S.

Looks like that will be one sweet router table.
Thx, no thread started... I'm already using it! lol

It's 1" melamine and 5/8" lexan insert.... Have it across two saw horses right now, need to build the cabinet soon. I decided the T-tracks could be better placed too... Not oriented right for feather boards, lol idk what I was thinking. Gonna prolly rebuild it all together...

Got a LOAD of free lexan and melamine from the last movie set I worked!!! :)
firemedic is offline
The Following User Says Thank You to firemedic For This Useful Post:
H. A. S. (02-09-2011)
post #9 of 10 Old 02-09-2011, 09:51 PM Thread Starter
Senior Member

Taylormade's Avatar

Join Date: Feb 2011
Location: Tampa, FL
Posts: 1,733
View Taylormade's Photo Album My Photos
As an update, I tested it on a scrap piece and no chipping to speak of, so I ran 6 routs across (after building c-man's jig, thanks again) with no chipping at all. Thanks for the confidence, fellas.

Ut Prosim
Taylormade is offline
post #10 of 10 Old 02-09-2011, 10:13 PM
Old School

cabinetman's Avatar

Join Date: Jul 2007
Location: So. Florida
Posts: 24,027
View cabinetman's Photo Album My Photos
Quote:
Originally Posted by Taylormade View Post
As an update, I tested it on a scrap piece and no chipping to speak of, so I ran 6 routs across (after building c-man's jig, thanks again) with no chipping at all. Thanks for the confidence, fellas.








.
cabinetman is offline
The Following User Says Thank You to cabinetman For This Useful Post:
Taylormade (02-09-2011)
