Project Question

I have a small side job for a customer, a bookcase and basically the same thing cut in half height wise that she wants to use as a 'TV stand/entertainment center'.

For a lack of better terms she wants 'side splashes' and a 'back splash' on the tops. Originally I was hoping to incorporate these into the frame or carcass, but am not sure of a solid way to join them.

At this point Im thinking a separate glued panel as an additional top (like I usually do anyway) and just glue and screw the 'splashes' on from underneath before I mount the top. I was hoping to avoid the extra work though.


Below is a picture of the top as the bookcase is now. Im basically looking for possible ideas on joining those 'splash' pieces as it sits.




Chamfer is offline
Sponsored Links
Advertisement

post #2 of 16 Old 01-23-2015, 08:23 PM
Senior Member

Join Date: May 2009
Location: northern illinois
Posts: 844
View mikeswoods's Photo Album My Photos
Do you have a pocket hole jig? Would that work for you?
mikeswoods is offline
post #3 of 16 Old 01-23-2015, 10:26 PM Thread Starter
Senior Member

Chamfer's Avatar

Join Date: Sep 2014
Location: Mechanicsville, VA
Posts: 1,450
View Chamfer's Photo Album My Photos
Thats actually not a bad idea, I hadnt thought of that probably because I dont have a jig lol. Normally I wouldnt consider something like that but since this is getting painted it could probably work.

Unfortunately I dont have the funds right now to get the only thing Id consider, a K4 or K5 kit.
Chamfer is offline
Sponsored Links
Advertisement

post #4 of 16 Old 01-23-2015, 10:34 PM
Senior Member

MT Stringer's Avatar

Join Date: Jul 2009
Location: Channelview, Tx
Posts: 2,642
View MT Stringer's Photo Album My Photos
I can't tell from the picture. Can you remove the top? That would be great if you can.
MT Stringer is offline
post #5 of 16 Old 01-24-2015, 09:06 AM Thread Starter
Senior Member

Chamfer's Avatar

Join Date: Sep 2014
Location: Mechanicsville, VA
Posts: 1,450
View Chamfer's Photo Album My Photos
No its glued into dados on the sides.
Chamfer is offline
post #6 of 16 Old 01-24-2015, 09:20 AM
Senior Member

Join Date: Dec 2008
Location: North Coast
Posts: 319
View Sawdustguy's Photo Album My Photos
If you can drill the top how about dowels or biscuits?
Sawdustguy is offline
post #7 of 16 Old 01-24-2015, 09:28 AM
Senior Member

Join Date: Jan 2013
Location: Buffalo NY
Posts: 255
View Black540i's Photo Album My Photos
How tall is the 'splash' as you call it? I think I would just drill in from the top and plug them. I'd say an accent wood color if you weren't painting it.
Black540i is offline
post #8 of 16 Old 01-24-2015, 09:28 AM
Senior Member

Join Date: Jan 2013
Location: Buffalo NY
Posts: 255
View Black540i's Photo Album My Photos
Drill and countersunk screws I meant. Then plugged over the screws.
Black540i is offline
post #9 of 16 Old 01-24-2015, 09:31 AM Thread Starter
Senior Member

Chamfer's Avatar

Join Date: Sep 2014
Location: Mechanicsville, VA
Posts: 1,450
View Chamfer's Photo Album My Photos
Quote:
Originally Posted by George G View Post
If you can drill the top how about dowels or biscuits?



Two things, first Im thinking biscuits would land about right at the joint line and was thinking is might weaken the joint. Second and more important I dont have clamps long enough to from the top of the side splash to the bottom of the case. Its 4ft tall without the splash.

Heres another picture to illustrate what I mean about the joint...



Chamfer is offline
post #10 of 16 Old 01-24-2015, 09:47 AM Thread Starter
Senior Member

Chamfer's Avatar

Join Date: Sep 2014
Location: Mechanicsville, VA
Posts: 1,450
View Chamfer's Photo Album My Photos
Quote:
Originally Posted by Black540i View Post
How tall is the 'splash' as you call it? I think I would just drill in from the top and plug them. I'd say an accent wood color if you weren't painting it.


They will be between 3-4" tall and I was planning on rounding over the tops so I dont know how well that would work (or look) screwing them from the top of the splash down into the top.


Here is a picture of what Im referring to or trying to accomplish. Mine will be taller and with more curves. If anyone has better terminology for what these are called PLEASE feel free to chime in.
