Question Reducing Dowels

I need to reduce the ends of 6 inch dowel rods from 3/8" diameter to 1/4". The total length of the reduced area is about 3/4" on each end. I could use a lathe but I am looking for a much faster way to produce a large number of these. Any ideas on how to get these done more quickly? I am open to all options.
DanManTX is offline
Sponsored Links
Advertisement

post #2 of 9 Old 12-10-2010, 04:44 PM
Senior Member

Longknife's Avatar

Join Date: Oct 2010
Location: UmeŚ, Sweden
Posts: 1,035
View Longknife's Photo Album My Photos
If you have a router table you can make a simple jig from a piece of scrap wood. Drill a hole in it, same diameter as the dowel. Use a straight router bit, set it to 3/4" height. Rout into the the jig until you reach the hole and a little bit more. Clamp the jig to the router table. Insert the dowel in the hole and turn it a full round. Check if the reduced diameter is 1/4". If not adjust the jig and try again.
Longknife is offline
post #3 of 9 Old 12-10-2010, 04:45 PM
Senior Member

phinds's Avatar

Join Date: Mar 2009
Location: Central New York
Posts: 3,248
View phinds's Photo Album My Photos
seems like a router table with a radius bit would be the perfect answer --- much faster than using a lathe, and more easily done, more repeatable. You WOULD get a curved section where the end changes size, though, and if that doesn't work for you you might make a router jig that would take the dowels straight down and up against a straight bit, then just twirl them around.

You can never have too much pepperoni on your pizza or own too many clamps.
www.hobbithouseinc.com/personal/woodpics/
phinds is offline
post #4 of 9 Old 12-10-2010, 04:58 PM
Junior Member

Tangelo's Avatar

Join Date: Nov 2010
Location: Chicagoland
Posts: 12
View Tangelo's Photo Album My Photos
Quote:
Originally Posted by DanManTX View Post
I need to reduce the ends of 6 inch dowel rods from 3/8" diameter to 1/4". The total length of the reduced area is about 3/4" on each end. I could use a lathe but I am looking for a much faster way to produce a large number of these. Any ideas on how to get these done more quickly? I am open to all options.
....

Last edited by Tangelo; 12-10-2010 at 05:06 PM. Reason: duplicate
Tangelo is offline
post #5 of 9 Old 12-10-2010, 05:02 PM
Junior Member

Tangelo's Avatar

Join Date: Nov 2010
Location: Chicagoland
Posts: 12
View Tangelo's Photo Album My Photos
Quote:
Originally Posted by DanManTX View Post
I need to reduce the ends of 6 inch dowel rods from 3/8" diameter to 1/4". The total length of the reduced area is about 3/4" on each end. I could use a lathe but I am looking for a much faster way to produce a large number of these. Any ideas on how to get these done more quickly? I am open to all options.

Hey DanmanTX, Rockler sells a Log Tenon Maker, see attached link. If you have a router, then this might work for you.

http://tinyurl.com/2u8kqto



Or you look at a Veritas 860-5404 1/4"Dia Mini Tenon Cutter from Amazon. http://tinyurl.com/2eb3gaj


I hope this helps. Let me know how it goes.

~Tangelo
Tangelo is offline
post #6 of 9 Old 12-11-2010, 11:04 AM Thread Starter
Junior Member

Join Date: Dec 2010
Posts: 2
View DanManTX's Photo Album My Photos
All good ideas

I will need a 90 degree shoulder cut on the round edges of the dowel so I don't the think the mini tenon cutter will work but I did not know they existed - so now I do! thanks!

I am going to move forward with the router table option and a straight bit. If a homemade jig is the best option, I'll try it but wonder if there's a commercial jig that will give me more precise and repeatable results. Any ideas?
DanManTX is offline
post #7 of 9 Old 12-11-2010, 01:09 PM
SS user

Gene Howe's Avatar

Join Date: Feb 2009
Location: Snowflake, AZ
Posts: 2,689
View Gene Howe's Photo Album My Photos
Plunge bit in the table. http://www.mlcswoodworking.com/shops.../bt_plung.html . Use Aux. fence, and raise the bit 1/8" into it. Back the fence up to expose the full width of the 3/4" bit. Now you have a stop. Use miter gauge or clamp a straight piece of wood 90 deg to the fence. Advance the dowel into the bit and rotate.
Gene Howe is offline
post #8 of 9 Old 12-12-2010, 11:08 AM
havin fun gettin it done

wdkits1's Avatar

Join Date: Jan 2009
Location: Midlothian, Va
Posts: 203
View wdkits1's Photo Album My Photos
Here is a jig that I made suggested by Longknife that works pretty good. I can see where this would work good for other types of tenons also.








Doesn't get any simpler than that.
wdkits1 is offline
post #9 of 9 Old 12-12-2010, 11:41 AM
Senior Member

JMC'sLT30's Avatar

Join Date: Oct 2010
Location: Somerville, Tn
Posts: 644
View JMC'sLT30's Photo Album My Photos
I like longknifes idea and would suggest maybe using an upper cut spiral to pull your waste into the direction of the router. Nice job wdkits.

"IF IT'S TOO TOUGH FOR THEM, IT'S JUST RIGHT FOR ME"
